Description
The EMS-81X is a compact two-way multipurpose loudspeaker intended for a variety of applications – either as a stand-alone product, or else with the incorporation of S-12 or other S Series subwoofers to make a truly fullrange system.
| Enclosure Type | Two-way passive, reflex loaded |
| Components | 1 x 8″ (203mm) neodymium LF drive unit 1 x 1″ (25mm) exit neodymium HF drive unit |
| Dimensions (HxWxD), mm/(ins) | 462 (18.2) x 262 (10.3) x 261 (10.3) |
| Net/Shipping Weight | 13/14kg (28.6/30.8lbs) |
| Frequency Response | 75Hz – 20kHz ± 3dB |
| Nominal Dispersion | 90° x 60°, rotatable (-6dB points) |
| Maximum SPL | 120dB continuous, 126dB peak |
| Loudspeakers per amplifier | DQ6: 2 per channel, DQ10: 4 per channel, DQ20: 4 per channel |
| Power Handling | 250W RMS, 500W program |
| Nominal Impedance | 8 ohms |
This is ex hire stock in good condition but not in original packaging, with substantial use. Asset tags have been removed without trace. Estimated manufacturer’s warranty already expired.
The following table shows the condition of stock released for sale:
| CALM Asset Tag | SerialNumber | Condition | |
|---|---|---|---|
| 892 | MS81030613/011 | Reserved for EU sale |
|
| 890 | MS81030613/003 | Reserved for EU sale |
